Indoor Inteligent Mechanical LED Display 10 Layers 1Face (Cambered Surface)
Indoor Inteligent Mechanical LED Display 10 Layers 1Face (Cambered Surface)
  Detail Parameter Remark
Display Display Model Indoor P2 Optional
Module Specification Flexible Module 320x160
Layers 10 Layer
Dimension Length 960mm;Width 188mm; Height 3700mm
Appearance Cambered Surface (Wide View Angle)
Faces 1Faces
Single Face Size per Layer 960x320/face
Total Size 960x3200（3.07m2）
Weight Around450KG
Height 3700mm
Max Power Consumption 5.8KW
Intelligent Control Rotating Mode Default Mode/Custom Mode Rotating Mode Optional according to play images
Rotating Speed Adjustable Moving Speed Adjustable according to customer or play images
On/Off Equipment on/off by touchscreen or mobile phone
Image Control Wireless upload  Tablet & PC uploading
Installation Power Supply 220V/380V 220 or 380V Power Only
Equipment Installation   Chasis Included
